Keysight Technologies 81134A Pulse Pattern Generator 3.35 GHz, dual-channel
Available for sale
The Keysight Agilent 81134A provides fast rise times and low intrinsic jitter for high-speed serial bus applications like PCI Express or Serial ATA, and for devices like receivers and backplanes. It also generates application-specific signal levels like pre- and de-emphasis (PCI Express) or squelch (Serial ATA). The Keysight Agilent 81134A lests your DUT instead of the pulse or data source.
展开剩余74%Other features of the Keysight Agilent 81134A:
Hardware-based PRBS
Memory-based pattern generation
Basic test patterns for Infiniband, PCI-Express and Serial ATA
Deep 12 MBit pattern memory per channel supports tests that require long data streams like disk drive tests
PC-based Pattern Management Tool, easier to handle long patterns: generate, modify and store patterns on a Microsoft Windows based PC and an easy-to-use function to quickly load the selected pattern to the 81134A using one of the remote control (GPIB, LAN USB 2.0) interfaces
Clock and data signals distortion
Versatile variable cross-point
Jitter insertion
Frequency, level and shape of injected jitter variation emulate real-world signals
Graphics User Interface: quick access to all relevant parameters
Controllable via the GPIP, USB 2.0, and LAN interfaces
Additional Features of the Keysight Agilent 81134A
Frequency range from 15 MHz - 3.35 GHz
Two ouput channels
Low jitter
Fast rise times (20%-80%) < 60 ps
Delay modulation (jitter emulation)
Variable cross-over point (eye deformation) LVDS applications can be addressed with output levels from 50 mV to 2 V Pre-/de-emphasis and squelch levels for PCI Express and serial ATA
LVDS applications can be addressed with output levels from 50 mV to 2 V
Pre-/de-emphasis and squelch levels for PCI Express and serial ATA
